Product Details
- Size: (3000X2000X2850)mm
- Place of Origin: Jinan
- Brand Name: stretch wrapping machine
- Model Number: T1800FZ-PL
- Weight: 800.000 kg
Max. Load size (mm) 1100(L)× 1100(W)× 2400(H)
Turntable diameter 1650mm (2000, 2100 available)
Turntable height 500mm (other available)
Turntable bearing capacity 2000kgs (2500, 3000 available)
Turntable speed 3-12rpm
Machine weight 1000kgs
Power supply 220V 50Hz 1Phase
Power 2.0kw
Air 0.4-06Mpa
Overall dimension 2745(L) × 1800(W) × 3330(H)
Packing efficiency 30-40 load/h, basing on load
Control System
PLC control system
Photo-eye pallet height sensor
0-9 separate top, bottom & up-down wrap count selectors
Photoeye sensing delay
Reinforce wrap allow more wrap on same location
Film Tension Control adjustment on the panel
312RPM variable turntable speed by frequency changer
Separate variable carriage up/down speed
Cycle pause capability
Separate start, reset and emergency stop buttons
Manual carriage up/down switch
Turntable jog button
Conveyor Jog (for each conveyor)
Dust-tight Precious Metal Slip-ring for long reliable service
Remote Control
Turntable
1800mm Diameter Structural steel plate
500mm high profile turntable
Position turntable alignment
Soft start/ Soft stop
Heavy duty chain drive
Table Fully Shrouded for Greater Personnel Safety
Film carriage
Powered pre-stretch system up to 200% to min film consumption(Prestretch ratio can be specially made according your requirements. )
Carriage door opens for effortless roll change and thread film
Film delivery variable speed by separate DC Drive Motor
Film dancer-bar with variable speed output
Heavy duty double-chain carriage lift, calm and safety
| Control system | PLC control system |
| Touch screen allows operation easily | |
| Auto sensing pallet arribe&start wrap cycle | |
| Auto cut&grab film after wrap finished | |
| Film tension control adjustable | |
| Separate variable carriage up /down speed | |
| Variable T/T rotation speed | |
| Safety tower light alarm | |
| Turntable | Go home position after wrap cycle finished |
| Soft start/soft stop | |
| Turntable slew bearing drive | |
| Table fully shrouded for greater personnel safety | |
| Film carriage | Powered pre-stretch system up to 300% to min film consumption(pre-stretch ratio van be specially made) |
| Carriage door opens for effortless roll change and thread film | |
| Technology Data | Max load size(mm):1100(L)X1100(W)X2400(H) |
| Turntable dia:1800mm(2000 available) | |
| Turntable Height:500mm(other available) | |
| Turntable weight capacity:2000kgs(2500,3000 available) | |
| Turntable speed:3-12rpm | |
| Electrics:220V 50HZ 1 phase | |
| Power:2.0 KW | |
| Packing efficiency:30-40 load/h base on load | |
| Air:0.4-0.6Mpa | |
| Machine weight:1000kgs | |
| Option | Addition conveyor & other type(chain,belt) avaiable |
| Safety fence | |
| Infed & outfeed conveyor | |
| Conveyor | Heavy structural steel fram construction |
| Heavy Duty Conveyor Guards | |
| Adjustable Leg Height | |
| Different Roller Diameters and Roll Spacing Available | |
| Photo-eye pallet sensing | |
| Auto film tail cut&wipe system | Pheumatic clamps grab the film tail after the wrapping finished |
| Hot wire cut film | |
| Pheumatic brush activate |
